Forged Through Toughness
The Africa Twin just got an upgrade. It's still the amazingly agile Adventure bike it has always been – with performance to push to the limit – but with extra low-down torque for drive. A new adjustable screen makes those on-road days much more comfortable. Tubeless tyres are easily repairable. And, the Electronic Suspension option of the Africa Twin ES, with Showa-EERA™, opens a whole new horizon of adventure.
CRF1100L Africa Twin ES
We’ve pressed the upgrade button. Firmly. The Africa Twin ES packs Showa Electronically Equipped Ride Adjustment (Showa-EERA™) which means optimum damping settings, all the time. Want a perfect base setting? Choose Mid. There’s also Hard, for progressive riding, touring, or carrying a pillion and luggage, Soft for easy manoeuvrability and Off-Road for precise suspension reaction away from tarmac. User allows total customisation (when stationary) and you can swap between modes – and adjust rear spring preload – while riding. The Africa Twin ES also packs heated grips and an ACC socket as standard.
Bore × Stroke (mm) | 92.0mm x 81.5mm |
Carburation | PGM-FI |
Compression Ratio | 10.5:1 |
Engine Displacement (cc) | 1084 cm3 |
Engine Type | Liquid-cooled 4-stroke 8-valve Parallel Twin with 270° crank and uni-cam |
Max. Power Output | 75.0kW/7500min |
Max. Torque | 112Nm/5,500rpm |
Starter | Electric |
Throttle Bore | 46mm |
C02 Emissions (g/km) | 114g/km |
Oil Capacity (Litres) | 5.2 |
ABS System | 2 channel with IMU Selectable ABS MODE with ON road and OFF road |
Brakes Front | 310mm dual wave floating hydraulic disc with aluminium hub and radial fit 4-piston calipers and sintered metal pads |
Brakes Rear | 256mm wave hydraulic disc with 2-piston caliper and sintered metal pads. 2-Channel with rear ABS off mode. |
Suspension Front | Showa 45mm cartridge-type inverted telescopic fork with dial-style preload adjuster and DF adjustments, 230mm stroke. |
Suspension Rear | Monoblock aluminium swing arm with Pro-Link with SHOWA gas-charged damper, hydraulic dial-style preload adjuster and rebound damping adjustments, 220 mm rear wheel travel. |
Tyres Front | Bridgestone BATTLAX ADVENTURECROSS TOURER AX41T Metzeler KAROO STREET |
Tyre Size Front | 90/90-21M/C 54H (Tubless) |
Tyre Size Rear | 150/70-R18M/C 70H (Tubless) |
Tyres Rear | Bridgestone BATTLAX ADVENTURECROSS TOURER AX41T Metzeler KAROO STREET |
Wheels Front | 21M/C x 2.15 Wire spoke with aluminium rim |
Wheels Rear | 18M/C x MT4.00 Wire spoke with aluminium rim |
Battery Capacity (VAh) | 12V-6Ah Li-ion BATTERY |
Caster Angle | 27.5° |
Dimensions (L×W×H) (mm) | 2330mm X 960mm X 1485mm |
Frame type | SemiDouble Cradle |
Fuel Tank Capacity (Litres) | 18.8L |
Fuel Consumption | 20.5km/l |
Ground Clearance (mm) | 250mm |
Headlights | |
Kerb Weight (kg) | 233 |
Seat Height (mm) | 850/870mm (Low Seat option 825mm, Comfort Seat option 885mm) |
Trail (mm) | 113 mm |
Wheelbase (mm) | 1575mm |
Turning Radius | 2.6 |
Clutch | 2 Wet multiplate clutches with coil springs |
Clutch Operation | Cable |
Final Drive | O-ring sealed chain |
Gearbox | 6-speed |
Transmission Type | Manual Clutch Transmission |
Quick Shifter | No |
12v Socket | Yes |
Headlights | LED |
Ignition System | Electronic, digital transistor |
Instruments | LCD METER 6.5inch TFT Touch Panel Multi information display |
Tail Light | LED |
Daytime Running Lights | Yes |
Cornering Lights | No |
Connectivity | Bluetooth audio and Apple CarPlay/Android Auto (wired) |
USB Socket | Yes (USB Type A, 1.5A) |
Self Cancelling Indicators | Yes |
Cruise Control | Yes |
Emergency Stop Signal | Yes |
Security | Immobiliser |
